0.5 Nm³/h Hydrogen Generator Specification Parameters |
|||
|
Category |
Component Name |
Parameter Description |
QTY |
|
Hydrogen ProductionCore Module |
Electrolyzer |
0.5 Nm³/h, Pressure 3MPa, 200A/10.5-12V (Customized) |
1 |
|
Power Supply |
AC380V；200A;0-15V |
1 |
|
|
Water Circulation Module
|
Water Tank |
6L(Customized) |
1 |
|
Heater |
175*400mm |
1 |
|
|
Connector |
Straight 4-part external threadX10*1mm external thread, 8mm quick connector, 8mm high-pressure hose, nut, sealing ring |
1 |
|
|
Liquid Level Sensor |
2 |
||
|
Ion Conductivity Sensor |
TDS |
2 |
|
|
Water Feed Pump |
24VWater Tank Filling |
1 |
|
|
Circulation Pump |
24V/30W 1.6~3L/minElectrolyzer Circulation Water |
1 |
|
|
Liquid Flow Meter |
Customized |
1 |
|
|
Purification Column |
Customized |
1 |
|
|
Heat Sink |
Customized |
1 |
|
|
Cooling Fam |
24V/1.5A 120mm*38mm |
2 |
|
|
Electrical Control Module
|
Digital Thermostat |
24V/600W，4mmProbe |
1 |
|
Hydrogen Generator Control Board |
1 |
||
|
Hydrogen Generator Control Board Glass Display |
1 |
||
|
Push Button Switch |
220V，Heater Power-On |
1 |
|
|
Push Button Switch |
3~24V，Control Board Power-On |
2 |
|
|
ACSocket |
220V/10A |
1 |
|
|
Hydrogen Gas Path Module |
Heat Sink |
Customized |
1 |
|
Cooling Fan |
24V/1.5A 120mm*38mm |
1 |
|
|
Steam-Water Separator |
304Stainless Steel,3MpaFilter |
1 |
|
|
Solenoid Drain Valve |
40kgSolenoid Drain Valve |
1 |
|
|
Molecular Sieve |
（Unit: Pound） |
10 |
|
|
Drying Tank |
Stainless Steel，≧3Mpa(Customized) |
2 |
|
|
Pressure Gauge Panel |
0~4MPA（Middle of Ferrule-Type Three-Way Connector） |
1 |
|
|
Pressure Switch |
3Mpa，1/4External Thread（Middle of Ferrule-Type Three-Way Connector） |
1 |
|
|
Pressuer Relief Valve |
Limit Pressure:3.Mpa |
1 |
|
|
Stainless Stell Connector |
Various Φ8 Ferrule-Type Connectors |
1 |
|
|
Hydrogen Alarm |
1 |
||
|
Chassis |
Steel Plate Enclosure |
Custom manufactured integrated enclosure, white baking paint |
1 |
1 Nm³/h Hydrogen Generator Specification Parameters |
|||
|
Category |
Component Name |
Parameter Description |
QTY |
|
Hydrogen Production Core Module |
Electrolyzer |
1 Nm³/h, Pressure 3MPa, 200A/21-26.4V(Customized) |
1 |
|
Power Supply |
AC380V；200A;0-30V |
1 |
|
|
Water Circulation Module
|
Water Tank |
6L(Customized) |
1 |
|
Heater |
175*400mm |
1 |
|
|
Connector |
Straight 4-part external thread X10*1mm external thread, 8mm quick connector, 8mm high-pressure hose, nut, sealing ring |
1 |
|
|
Liquid Level Sensor |
2 |
||
|
Ion Conductivity Sensor |
TDS |
2 |
|
|
Water Feed Pump |
24V Water Tank Filling |
1 |
|
|
Circulation Pump |
24V/30W 1.6~3L/min Electrolyzer Circulation Water |
1 |
|
|
Liquid Flow Meter |
Customized |
1 |
|
|
Purification Column |
Customized |
1 |
|
|
Heat Sink |
Customized |
1 |
|
|
Cooling Fam |
24V/1.5A 120mm*38mm |
2 |
|
|
Electrical Control Module
|
Digital Thermostat |
24V/600W，4mm Probe |
1 |
|
Hydrogen Generator Control Board |
1 |
||
|
Hydrogen Generator Control Board Glass Display |
1 |
||
|
Push Button Switch |
220V，Heater Power-On |
1 |
|
|
Push Button Switch |
3~24V，Control Board Power-On |
2 |
|
|
AC Socket |
220V/10A |
1 |
|
|
Hydrogen Gas Path Module |
Heat Sink |
Customized |
1 |
|
Cooling Fan |
24V/1.5A 120mm*38mm |
1 |
|
|
Steam-Water Separator |
304Stainless Steel, 3Mpa Filter |
1 |
|
|
Solenoid Drain Valve |
40kg Solenoid Drain Valve |
1 |
|
|
Molecular Sieve |
（Unit: Pound） |
10 |
|
|
Drying Tank |
Stainless Steel，≧3Mpa (Customized) |
2 |
|
|
Pressure Gauge Panel |
0~4MPA（Middle of Ferrule-Type Three-Way Connector） |
1 |
|
|
Pressure Switch |
3Mpa，1/4 External Thread（Middle of Ferrule-Type Three-Way Connector） |
1 |
|
|
Pressuer Relief Valve |
Limit Pressure: 3.Mpa |
1 |
|
|
Stainless Stell Connector |
Various Φ8 Ferrule-Type Connectors |
1 |
|
|
Hydrogen Alarm |
1 |
||
|
Chassis |
Steel Plate Enclosure |
Custom manufactured integrated enclosure, white baking paint |
1 |
2 Nm³/h Hydrogen Generator Specification Parameters |
|||
|
Category |
Component Name |
Parameter Description |
QTY |
|
Hydrogen Production Core Module |
Electrolyzer |
2 Nm³/h, Pressure 3MPa, 200A/42-48V(Customized) |
1 |
|
Power Supply |
AC380V；200A;0-60V |
1 |
|
|
Water Circulation Module
|
Water Tank |
6L(Customized) |
1 |
|
Heater |
175*400mm |
1 |
|
|
Connector |
Straight 4-part external thread X10*1mm external thread, 8mm quick connector, 8mm high-pressure hose, nut, sealing ring |
1 |
|
|
Liquid Level Sensor |
2 |
||
|
Ion Conductivity Sensor |
TDS |
2 |
|
|
Water Feed Pump |
24V Water Tank Filling |
1 |
|
|
Circulation Pump |
24V/30W 1.6~3L/min Electrolyzer Circulation Water |
1 |
|
|
Liquid Flow Meter |
Customized |
1 |
|
|
Purification Column |
Customized |
1 |
|
|
Heat Sink |
Customized |
1 |
|
|
Cooling Fam |
24V/1.5A 120mm*38mm |
2 |
|
|
Electrical Control Module
|
Digital Thermostat |
24V/600W，4mm Probe |
1 |
|
Hydrogen Generator Control Board |
1 |
||
|
Hydrogen Generator Control Board Glass Display |
1 |
||
|
Push Button Switch |
220V，Heater Power-On |
1 |
|
|
Push Button Switch |
3~24V，Control Board Power-On |
2 |
|
|
AC Socket |
220V/10A |
1 |
|
|
Hydrogen Gas Path Module |
Heat Sink |
Customized |
1 |
|
Cooling Fan |
24V/1.5A 120mm*38mm |
1 |
|
|
Steam-Water Separator |
304Stainless Steel, 3Mpa Filter |
1 |
|
|
Solenoid Drain Valve |
40kg Solenoid Drain Valve |
1 |
|
|
Molecular Sieve |
（Unit: Pound） |
10 |
|
|
Drying Tank |
Stainless Steel，≧3Mpa (Customized) |
2 |
|
|
Pressure Gauge Panel |
0~4MPA（Middle of Ferrule-Type Three-Way Connector） |
1 |
|
|
Pressure Switch |
3Mpa，1/4 External Thread（Middle of Ferrule-Type Three-Way Connector） |
1 |
|
|
Pressuer Relief Valve |
Limit Pressure: 3.Mpa |
1 |
|
|
Stainless Stell Connector |
Various Φ8 Ferrule-Type Connectors |
1 |
|
|
Hydrogen Alarm |
1 |
||
|
Chassis |
Steel Plate Enclosure |
Custom manufactured integrated enclosure, white baking paint |
1 |
